Features
| Usage |
|
| 特点 |
|
Specifications
| 型号 | 测定范围 | 本体精度（μm） | 基本尺寸（mm） | 标准配件 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | 邻接误差 | 全测定范围 | 重复精度 | 全长A | 可测深B | 测头高C | 测头（支） | 垫片（mm） | 延长杆（mm） | |
| CC-1HS | 18-35 | 2 | 5 | 2 | 148.75 | 50 | 5.75 | 9 | 0.5,1 | – |
| CC-2HS | 35-60 | 151.5 | 50 | 8.5 | 6 | 1,2,3 | – | |||
| CC-3HS | 50-100 | 151.6 | 50 | 8.6 | 11 | 1,2,3 | – | |||
| CC-3CHS | 50-150 | 151.6 | 50 | 8.6 | 11 | 1,2,3 | 5 | |||
Source reference: Super Tooling (Shenzhen) — partner-supplied precision tooling specifications, distributed by Merex Precision Tools with full traceability and pre-sales engineering support.
For OEM bulk pricing, dimensional drawings (PDF/STEP), or sample evaluation units, contact [email protected]. Application engineers respond within one business day.
Request a Quote / Inquiry
Pricing and availability for PEACOCK CC-02 Standard cylinder gauge (SKU: PEACOCK-01-CC-1HS-01) may change frequently.
Send us your requirements and we will respond within 1 business day.
