KANON 09-HYK-01 — Wrench

Precision Measuring Tool MT-2803 — Merex Precision Tools (image from industrial component)

Written by

in

Features

特点
  • 扳手头可根据使用要求进行拆卸和倒转
  • 活动开口型,比较不受限于六角螺帽对边的尺寸，应用范围更广
  • 可在 30 度以下的狭窄工作空间中使用，这是其他产品无法做到的
  • 扳手头中的蜗杆调节器几乎没有任何间隙，这将提高工作效率，也不会像普通扳手那样损坏紧固件的边角
  • 只能按箭头方向紧固
  • 取下活动开口头，可更换为QCK,SCK,RCK,HCK扳手头使用
  • 精度保证在±4%以内
Usage
  • 适合拧紧具有不同扭矩的多种类型的螺栓和螺母
  • 最适合汽车、两轮车、机械等具有扭力要求的螺栓、螺母紧固，空调、暖气配管的紧固作业

Specifications

型号 调整范围 最小读值 型号 调整范围 最小读值 全长 开口尺寸 头部尺寸（mm） 主体尺寸（mm）
公制 Kgf · cm 牛顿 N · m mm S D T1 T2 A B φC
500HYK 100-500 5 N50HYK 10-50 0.5 288 10-25 48 10 5.5 25 11.4 20
1000HYK 200-1000 10 N100HYK 20-100 1 393 10-30 58 12 6.0 27.5 12.4 21.7
2000HYK 400-2000 20 N200HYK 40-200 2 531 17-38 66 12.5 6.5 15.4 15.4 27.2
